ZLA-25L Semi-automatic Auger filling machine
Descriptive abstract
This type can do dosing and filling work. Due to the special professional design, so it is suitable to the fluidic or low-fluidity materials, like coffee powder, wheat flour, condiment, solid drink, veterinary drugs, dextrose, pharmaceuticals, powder additive, talcum powder, agriculture pesticide, dyestuff, and so on.
Hovedtræk
Stainless steel structure；Quick disconnecting or split hopper could be washed easily without tools.
Servo motor drive screw.
PLC & touch screen make it be easy of operation.
Vægt tilbagemelding og proportionsspor slippe af med manglen på variabel pakket vægt for forskellige forhold af forskellige materialer.
Save the parameter of different filling weight for different materials. To save 10 sets at most
Replacing the auger parts, it is suitable for material from super thin powder to granule.
Main Technical Dat-en
| Hopper | Quick disconnecting hopper 25L |
| Pakningsvægt | 10 - 1000g |
| Pakkens nøjagtighed | ≤ 100g,≤±2%; 100 – 500g, ≤±1%; ≥500g,≤±0.5% |
| Fyldningshastighed | 5 – 20 times per min |
| Strømforsyning | 3P AC208-415V 50/60Hz |
| Total effekt | 2.25Kw |
| Totalvægt | 350 kg |
| Overall Dimensions | 1205×1010×2174mm |
